DESCRIPTION:

Working Principle: The Gravity Thickener is a compact and virtually maintenance-free, Gravity Thickener can be adjusting according to process conditions such as throughput and inlet consistency. The pulp suspension is fed at a consistency of 0.9 to 2.5% to the inlet chamber into the vat in the same direction as disc rotation. Thickening is capacity ensured by the number of disc installed in the centre shaft. The thickener vat level and outlet consistency which are controlled by thickener speed through VFD. The filtrate is discharged either at one or both shaft ends by gravity, depending on the thickeneer size. Gravity Thickener permits the installation of a large dewatering area at minimum floor space. Application & Salient Features: - Extremely compact design small floor place- Quality of Filtrate water- Efficient and reliable dewatering- Auto door opening- Easy and simple operation and maintenance-free- Fully assembled for minimum site erection Types of Models - 1. TPD: 100-150Power: 11 kWArea: 75 m sq. 2. TPD: 200-250Power: 15 kWArea: 125 m sq. 3. TPD: 250-300Power: 22 kWArea: 150 m sq. Specification/Additional Details Stages - custom Automation Grade - custom Voltage - 11kW,15kW,22kW Motor - Motor RPM=1440 Material - Stainless Steel Usage/Application - Industrial Color - Steel Physical State - Solid Brand - Parason Suitable for - Paper Pulp
