China Techsure Industrial Co., Ltd.

DESCRIPTION:

Characteristics:<br><br>Higher working speed<br>Adopt PLC control, each unit driven by independent motor, failure rate decreased, good synchronism avoid wrinkle of web<br>Adopt winding shaft instead of air shaft, easy to change log<br>Easy to adjust slitting size<br>Slitting blade can move in cross direction by pneumatic control<br><br><br>Optional Items:<br>Adjustable Perforating Size<br>1-4 plies backstand, with shaft or shaftless type<br>Embossing: steel to rubber/felted/woolen<br>Edge embossing: air bag type<br><br><br>Mode ZQ-D250 1092/1575/1760/2500/2900 <br> Max Width of the web 1350/1750/2000/2400/2800mm <br> Design Speed 0-250m/min <br> Operation Speed 0-230m/min <br> Max Diameter of the jumbo 1100mm <br> Inner Diameter of the jumbo core 76mm <br> Outter Diameter of the finished product 90-350mm <br> Outter Diameter of finish product core 76mm <br> Product Finish Condition Total length and diameter <br> Product Diameter Control Electric Pneumatic Control <br> Installed Power 4-22kw <br> Slitting Width Adjusting 10mm <br> Winding Pneumatic Shaft<br> Brake Electric Pneumatic Control <br> Pneumatic System 4HP air compressor, prepared by user<br> Perforating Blade 4 pcs spiral blades <br> Perforating Size 110mm ±3mm <br>
