Kai Way Printing and Packaging Machinery Co., Ltd.

DESCRIPTION:

Two-Piece Joint Stitching Machine (Two Pieces with Double Servo Control) Brand: Kai Way Model: KW-DS-1600/2400/2700/3000 Max. Sheet Size (L+Wmm):4800/5400/6000 Min. Sheet Size (mm): 1060/1060/1060 Max. Sheet Length (mm):2250/2250/2850 Min. Sheet Length (mm): 350/350/350 Max. Sheet Width (mm):1200/1350/1500 Min. Sheet Width (mm): 180/180/180 Min. Sheet Height (mm): 400/400/400 Nail Spacing (small-large): 0-120 Nail number: 1-99 Machine Stitching Speed: 500 Nail/Minute Nail Type: Single, Double, Reinforced Nail finished Once Power Required: 18HP Machine Weight : 4000kg/4100kg/4200kg Max Slotting Nail Length: 600mm (C) Max TS Width Ma: 45mm (E) Paperboard Applied : 3 Layer/5Layer Corruaged Paperboard (7 Layers at buyer option) Thickness (3mm-8mm) Min First Nail Position: 25mm (D) 25mm (D)without lid Kai Way KW-DS series Two-piece Joint Stitcher can stitch single-sheet or double-sheet formed cartons whether they are regular or not. Half-slotted and large-sized cartons can be also nailed by it. The machine adopts full electric control. The speed of nailing box is fast and energy-saving. Paper feeding part of the machine takes up automatic counting. And the finished-product is discharged for binding. If the carton specification is switched, it only takes two to three minutes to complete adjustment. It is fairly convenient and fast to operate. In addition, the machine can nail single-nail, double nails and reinforced nails showing that it has fairly greater flexibility. The machine automatically adjusts nail spacing through computer setting. The computer screen can display failure prompt for fast troubleshooting.
